SIEMENS SITRANS FM MAG 5000 electromagnetic flow transmitter

The SITRANS FM MAG 5000 is a microprocessor-based transmitter engineered for high performance, easy installation, commissioning and maintenance. The transmitter is truly robust, cost-effective and suitable for all-round applications and has a measuring accuracy of ± 0.4% of the flow rate (incl. sensor).

Benefits:

• Cost-effective transmitter offering high performance.
• Rugged construction suitable for universal applications and providing high measurement accuracy.
• Multiple function outputs for efficient process control.
• Display and keypad available in several languages, ensuring ease of use.
• Integration with SITRANS FM portfolio: The MAG 500/6000 transmitter can be flexibly used with all products (MAG 5100/3100/1100).
• Unique SensorProm technology: Critical, sensor-specific data is stored and passed to the transmitter, allowing for simple and flexible sensor commissioning.
• Plug & Play: Enables easy on-site replacement and commissioning of the transmitter in just minutes.
• “Hot swappable”: The transmitter can be exchanged during operation.
• Mounting flexibility: Compact or separate installation options are available.
• Validated calibration: Each Siemens flowmeter is calibrated in facilities accredited to ISO/IEC 17025, ensuring accurate flow measurement.
• Service and diagnostics: Designed for MAG on-site verification with traceable certification. Regular calibration of the SITRANS FM Verificator ensures accuracy in the field.

• Detail

  Accuracy	0.4 % ±1 mm/s
  Input / output	1 current output 1 digital output 1 relay output
  Communication	HART
  Display	Background illumination with?alphanumeric text, 3 x 20 characters
  Enclosure	IP67 (NEMA 4x/6) IP20 (NEMA 2)
  Power supply	12-24 V a.c./d.c. 115-230 V a.c.
  Ambient temperature	From -20 to 50 °C (-4 to 122 °F)
  Approvals	MI-001 Danak PTB OIML R49
  Ex-approvals	FM/CSA Class 1, Div 2
