Specifications
- Mass flow accuracy (Liquid)
- ±0.10% of rate (standard)±0.05% of rate (optional)
- Mass flow repeatability (Liquid)
- ±0.05% of rate (standard)±0.025% of rate (optional)
- Volume flow accuracy (Liquid)
- ±0.10% of rate (standard)±0.05% of rate (optional)
- Volume flow repeatability (Liquid)
- ±0.05% of rate (standard)±0.025% of rate (optional)
- Mass flow accuracy (Gas)
- ±0.35% of rate
- Mass flow repeatability (Gas)
- ±0.20% of rate
- Density accuracy (Liquid)
- ±0.0005 g/cm3 (±0.5 kg/m3) (standard)±0.0002 g/cm3 (±0.2 kg/m3) (optional)
- Density repeatability (Liquid)
- ±0.0002 g/cm3 (±0.2 kg/m3) (standard)±0.0001 g/cm3 (±0.1 kg/m3) (optional)
- Temperature accuracy
- ±1 °C ±0.5% of reading
- Sensor maximum working pressure
- 2,973 psig (205 barg)
- Meter approvals, calibrations, and certifications
- ?UL
?CSA
?IECEx
?NEPSI
?ATEX
?Ingress Protection
?EMC effects
Features
Experience unrivaled measurement sensitivity and stability with this uniquely designed meter.
Ensure real-time and in-process measurement integrity with the assurance provided by Smart Meter Verification.
Achieve unparalleled performance in measuring flow and density, even in the most challenging liquid, gas, and slurry applications.
Attain exceptional measurement confidence with the highest immunity to fluid, process, and environmental effects.
Enhance scalability with a wide range of application coverage, including hygienic, cryogenic, and high-pressure environments.
Benefit from the widest process-measurement range available, spanning from -400°F to 662°F (-240°C to 350°C) and up to 6,000 psig (414 barg).
Enjoy the broadest range of meter approvals and certifications, including CSA, ATEX, NEPSI, IECEx, Ingress Protection 66/67, SIL2 and SIL3, marine, and custody transfer approvals.
Choose from options such as a rupture disk or purge fitting case.
Explore our ELITE Coriolis Flow and Density Meters in greater detail by interacting with our 3D model.
